Item

P1.953

P2.604

P2.976

P3.91

Pixel Pitch(mm)

1.953

2.604

2.976

3.91

LED Type

SMD1515

SMD1515

SMD1515

SMD2121

Pixel Density(dots/㎡)

26144

147456

112896

65536

Module Dimension(MM)

250*250

250*250

250*250

250*250

Module Resolution(Dots)

128*128

96*96

84*84

64*64

Cabinet Dimension(MM)

1000*250MM(1000*500MM,500*250MM,500*500MM Optionl)

Scan Method(Scan)

1/32

1/32

1/16

1/16

Power Consumption

(Max/Average)

700/230W

700/230W

700/230W

700/230W

Brightness(Nits)

600

600-800

800-1200

800-1200

Color Depth

14

Refresh Rate(Hz)

1920Hz/3840Hz

View Angle(°)

H:160°/V:160°

AC Input Frequency(Hz)

AC110V/220V 50/60HZ

Operate Temp(℃)

-30℃~+50℃

Storage/Operate Humidity

10-90%RH

IP Rating

IP40/IP20

Instrallation/Maintenance

Front Installation and Front Maintenace

Weight

5kg/pc(1000*250MM)
