Item

P0.9375

P1.25

P1.5625

P1.875

P2.5

Pixel Pitch(mm)

0.9375

1.25

1.5625

1.875

2.5

LED Type

Mini LED

SMD1010

SMD1010

SMD1010

SMD2121

Pixel Density(dots/㎡)

1137777

640000

409600

284444

160000

Module Dimension(MM)

300*168.7

150*168.7

150*168.7

150*168.7

150*168.7

Module Resolution(Dots)

320*180

120*135

96*108

80*90

60*68

Cabinet Dimension(MM)

600*337.5MM

Scan Method(Scan)

1/60

1/64

1/64

1/32

1/32

Power Consumption

(Max/Average)

700/230W

700/230W

700/230W

800/240W

800/240W

Brightness(Nits)

400-500

600

600-800

600-800

800-1200

Color Depth

14

Refresh Rate(Hz)

1920Hz/3840Hz

View Angle(°)

H:160°/V:160°

AC Input Frequency(Hz)

AC110V/220V 50/60HZ

Operate Temp(℃)

-30℃~+50℃

Storage/Operate Humidity

10-90%RH

IP Rating

IP40/IP20

Instrallation/Maintenance

Front Installation and Front Maintenace

Weight

7kg/pc
